DVS Series Managed Industrial Ethernet Switches User’s Manual
An SNMP agent sends SNMP trap messages to the trap community (trap receiver). It monitors the
switch for particular events or conditions, and generates trap messages based on these events or
conditions.
Trap Config
uration
Description Factory Default
Community Name
Enter a case-sensitive string. The maximum length is 16 characters.
Maximum trap is 10.
None
Version
Specify the SNMP version that is used for the trap community:
 SNMP V1: Uses SNMPv1 to send traps to the trap community.
 SNMP V2: Uses SNMPv2 to send traps to the trap community.
None
Protocol
Specify the IP version that is used for the trap community:
 IPv4: Sends traps to an IPv4 address. Input an IPv4 address in the
Address field.
 IPv6: Sends traps to an IPv6 address. Input an IPv6 address in the
Address field.
None
Address
Enter an IPv4 or IPv6 address according to the selection in the Protocol
drop-down list. For an IPv6 address, enter the address as
xxxx:xxxx:xxxx:xxxxx:xxxx:xxxx:xxxx:xxxx format.
None
3.2.1.3 Trap Flags
After you configure the trap communities, you also need to configure what kinds of SNMP traps the
switch can generate and send. When the switch detects the active trap which is an identified
condition, a trap will be sent to the trap communities.
3-34
