DVS Series Managed Industrial Ethernet Switches User’s Manual
3.5.2 IGMP VLAN Configuration
This page can configure the IGMP snooping and querier status to each VLAN.
IGMP VLAN Con
figuration
Description Factory Default
VLAN ID
Select a VLAN ID for which you want to create an IGMP snooping
configuration.
None
Admin Mode
Specify the IGMP querying status for VLAN:
 Disable: The query can’t be forwarded to all multicast groups in
VLAN.
 Enable: The query can be forwarded to all multicast groups in
VLAN.
Enable
Configured Querier Status
Specify the configured querier status:
 Disable: IGMP querying is disabled for VLAN. You can still
configure VLAN for snooping, but the settings do not take effect after
you have applied them.
 Enable: IGMP querying is enabled for the VLAN.
Disable
Current Querier Status
The field displays the current querier status in the VLAN. Disable
Maximum Response Time (tenths of a second)
Enter the maximum response time for the IGMP query for VLAN. This
field specifies the maximum period that the switch waits for a response
from a host if the switch is the querier for VLAN. Enter a period in
tenths of seconds in the range of 0 to 255. Enter 0 to disable the
maximum response time.
100
3-64
