Delta DVS Series User Manual

Chapter 3 Featured Functions
3.6.1.2 CoS Queue Mapping
This page provides you to configure CoS value to physical queue mapping table. The field specifies
a priority value between 0 and 7, and Delta switch provide 4 physical queues which can be used by
quality of service (QoS) to differentiate network traffic.
Interface Selection
Specify one o
f the following selections:
•Select from 0/1 through 0/10: Specify an individual interface.
•Select from po1 through po3: Specify a link aggregation group.
•Select All: Specify all interfaces and link aggregation groups.
CoS Queue Mapping
Select a queue to which you want to map the priority. The traffic class is the selected queue (Low,
Normal, Medium, or High) for an interface.
The default queues of the CoS are mapped as below:
CoS
0 1 2 3 4 5 6 7
Queue
Normal Low Low Normal Medium Medium High High
3-69
