Section 7 — Effect Parameters TS-12 Musician’s Manual
14
EIGHT VOICE CHORUS Signal Routing
FX-1 Left
FX-2 Left
FX-1 Right
FX-2 Right
Delay
Regen
4 Voice
Chorus
4 Voice
Chorus
L
Main
Outputs
R
Delay
Delay
Chorus Regen
Chorus Regen
CHORUS RATE Range: 00 to 99
Controls the eight ganged rates of modulation of the respective voices and produces an effect
similar to both vibrato and tremolando occurring at the same time.
WIDTH Range: 00 to 99
Controls the excursion of the vibrato of all the individual voices.
REGEN Range: 00 to 99
Determines the amount of signal that will be fed from the output of the chorus back into the
input of the chorus. A value of 00 will eliminate the regeneration effect.
STEREO SPREAD Range: 00 to 99
This parameter offers a synthesized stereo field. The highest value is true stereo, intermediate
values have the left and right signals mixed on both sides, and the lowest value yields only the
left input channel from the right and left outputs. This parameter, though not a stereo pan,
provides some interesting stereo effects when controlled by a modulation source.
DELAY REGEN Range: 00 to 99
Determines the amount of signal that will be fed from the delay output back into the chorus
input, increasing the number of repeats in the delay for high values. A value of 00 will eliminate
the delay effect.
TIME L Range: 0000 to 0800 ms
Controls the amount of time that the non-chorused signal will delay for the left channel.
TIME R Range: 0000 to 0800 ms
Controls the amount of time that the non-chorused signal will delay for the right channel.
45 CHORUS + REVERB 1
This effect combines a four-voice chorus with the standard reverb. Assign a voice to FX-1 to get
reverb after chorus, or use FX-2 for reverb only.
CHORUS MIX Range: 00 to 99
Controls the Dry/Wet mix within the chorus itself.
RATE Range: 00 to 99
Controls the four rates of modulation of the delay time of the chorus. The delay modulation
produces vibrato and tremolo.
To Next Page
