Section 7 — Effect Parameters TS-12 Musician’s Manual
22
ECHO - LEVEL Range: 00 to 99
Controls the volume of the discrete echo for both the left and right sides. Higher values offer
louder echo, while a value of 00 will eliminate the echo. For sustained sounds, mid echo levels
yield a “poor man’s reverb.”
TIME (L and R) Ranges: 0000 to 1500 msec
These parameters control the chorus echo time. Higher settings yield a deeper echo. There are
two discrete echoes, one to the left and one to the right.
EQ TRIM Range: -24 to +00 dB
Allows you to adjust the input volume of the EQs to eliminate the possibility of clipping boosted
signals.
BASS FC Range: 0000 to 1000 Hz
Sets the cutoff-frequency of the lower-frequency band shelving filter.
LEVEL Range: -48 to +24 dB
Sets the amount of boost or cut applied to the low shelving filter.
TREBLE FC Range: 01KHz to 15KHz
Sets the cutoff-frequency of the high shelving filter.
LEVEL Range: -48 to +24 dB
Sets the amount of boost or cut applied to the high shelving filter.
51 FLANGER + REVERB
The FLANGER + REVERB algorithm is similar to the CHORUS + REVERB algorithm with a
single LFO. Assign a voice to FX-1 to get reverb after flange, or use FX-2 for reverb only.
FLANGER CENTER Range: 00 to 99
Controls the center of the flanger width.
RATE Range: 00 to 99
Controls the rate of modulation of the flanger effect.
WIDTH Range: 00 to 99
Controls the range of the high to low-frequency sweep in the flanger effect.
REGEN Range: -99 to +99
Controls the amount of feedback applied to the flanger. The sign of the value determines the
polarity of the feedback.
DEPTH Range: 00 to 99
Controls the depth of the notches created by the flanging effect.
DECAY TIME Range: 0.20 to 100.0
Controls the amount of time it takes for the reverberation to decay to a low level (-60 dB) after the
input signal stops.
EARLY REF LEV Range: 00 to 99
Controls the level of pre-echoes of the input signal added directly to the reverb output.
