Installation Specification
Item Specification
Outer dimensions (W × D × H) (*1) 300 × 202 × 170 mm/11.81 × 7.95 × 6.69
in.
Installation space (W × D × H) (*2) 400 × 700 × 380 mm/15.75 × 27.56 ×
14.96 in.
Weight 4.9 kg (10.80 lb) or less
Input power Voltage range AC 100 to 240 V ±10%
Phase Single phase
Frequency range 50/60 Hz ±3 Hz
Power consumption Operating 42 W or less
Power saving 2.4 W or less
Power off Less than 0.35 W
Ambient conditions Temperature Operating: 5 to 35℃ (41 to 95°F)
Not operating: -20 to 60℃ (-4 to 140°F)
Humidity Operating: 20 to 80%
Not operating: 8 to 95%
Calorific value Operating 36.12 kcal/hr or less
Power saving 2.07 kcal/hr or less
Shipping weight (*3) 7.2 kg (15.88 lb) or less
Support period 5 years
*1:The depth indicates the size of the scanner without the ADF paper chute (feeder) and the stacker.
*2:The required installation space is a reference for scanning A4 size documents.
*3:Includes the package weight.
Appendix
306
