GE P642 User Manual

Appendix A - Ordering Options
P64x
Variants Order Number
P642 Transformer Protection P642 **
V
x Aux Rating :
24 - 54Vdc 7
48 - 125Vdc (40 - 100Vac) 8
110 - 250 Vdc (100 - 240 Vac) 9
In/Vn Rating :
HV-LV (In = 1A/5A), (Vn = 100/120V) (8CT/1VT) 1
HV-LV (In = 1A/5A), (Vn = 100/120V) (8CT/2VT) 2
Hardware Options :
Standard - no options 1
IRIG-B only (modulated) 2
Fibre optic converter only 3
IRIG-B (modulated) & fibre optic converter 4
Ethernet (100Mbit/s) 6
Second Rear Comms Port (Courier EIA232/EIA485/k-bus) 7
Second Rear Comms Port + IRIG-B (modulated) (Courier EIA232/EIA485/k-bus) 8
Ethernet (100Mbit/s) plus IRIG-B (Modulated)
A
Ethernet (100Mbit/s) plus IRIG-B (Un-modulated) B
IRIG-B (Un-modulated) C
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Modulated IRIG-B G
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Un-modulated IRIG-B H
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Modulated IRIG-B J
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Un-modulated IRIG-B K
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Modulated IRIG-B L
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Un-modulated IRIG-B M
Redundant Ethernet PRP/HSR*, 2 fibre ports + Modulated IRIG-B
N
Redundant Ethernet PRP/HSR*, 2 fibre ports + Unmodulated IRIG-B
P
* HSR – contact Alstom for details
Product Specific Options :
Size 8 (40TE) Case, 8 Optos + 8 Relays
A
Size 8 (40TE) Case, 8 Optos + 8 Relays + RTD B
Size 8 (40TE) Case, 8 Optos + 8 Relays + CLIO (mA I/O) C
Size 8 (40TE) Case, 12 Optos + 12 Relays D
Size 8 (40TE) Case, 8 Optos + 12 Relays (including 4 High Break) E
Protocol Options :
K-Bus/Courier 1
Modbus 2
IEC60870-5-103 3
DNP3.0 4
IEC 61850 over Ethernet and Courier via rear K-Bus/RS485 6
DNP3.0 over Ethernet and Courier via rear K-Bus/RS485 8
Mounting Options :
Panel Mounting, with Harsh Environment Coating M
Panel Mounting, with harsh environment coating P
Language Options :
English, French, German, Spanish 0
English, French, German, Russian 5
Chinese, English or French via HMI, with English or French only via Communications port C
Software Version Options :
Unless specified the latest version will be delivered **
Customisation :
Default 0
Customer Settings
A
Design Suffix :
Factory Determined
A1
