Terminal Number RTD connection
Terminal 17 RTD6 wire 2
Terminal 18 RTD6 wire 3
Terminal 19 RTD7 wire 1
Terminal 20 RTD7 wire 2
Terminal 21 RTD7 wire 3
Terminal 22 RTD8 wire 1
Terminal 23 RTD8 wire 2
Terminal 24 RTD8 wire 3
Terminal 25 RTD9 wire 1
Terminal 26 RTD9 wire 2
Terminal 27 RTD9 wire 3
Terminal 28 RTD10 wire 1
Terminal 29 RTD10 wire 2
Terminal 30 RTD10 wire 3
6.13 CLIO BOARD
Figure 28: RTD board
The CLIO boar
d provides two banks of 15 terminals to support four current loop inputs and four current loop
outputs. There are three terminals for each input and three for each output, therefore 24 of the terminals are used
altogether. The CLIO board fits into slot B or slot C, depending on the model variant.
The terminal numbers of the current loop inputs and outputs are as follows:
P64x Chapter 3 - Hardware Design
P64x-TM-EN-1.3 59
