GE P642 User Manual

Case width (TE) Case width (mm) Case width (inches)
40TE 203.2 8
60TE 304.8 12
80TE 406.4 16
Note:
Not all case sizes ar
e available for all models.
3.2 LIST OF BOARDS
The product's hardware consists of several modules drawn from a standard range. The exact specification and
number of har
dware modules depends on the model number and variant. Depending on the exact model, the
product in question will use a selection of the following boards.
Board Use
Main Processor board – 40TE or smaller Main Processor board – without support for function keys
Main Processor board – 60TE or larger Main Processor board – with support for function keys
Power supply board 24/54 V DC Power supply input. Accepts DC voltage between 24 V and 54 V
Power supply board - 48/125 V DC Power supply input. Accepts DC voltage between 48 V and 125 V
Power supply board 110/250 V DC Power supply input. Accepts DC voltage between 110 V and 250 V
Instrument Transformer board Contains the voltage and current transformers
Input board Contains the A/D conversion circuitry
Input board with opto-inputs Contains the A/D conversion circuitry + 8 digital opto-inputs
Opto-input board Contains 8 digital opto-inputs
Output relay board Contains 8 digital output relays
Combined Opto-input / Output relay board Contains 4 digital opto-inputs and 4 digital output relays
IRIG-B board - modulated Interface board for modulated IRIG-B timing signal
IRIG-B - demodulated input Interface board for demodulated IRIG-B timing signal
Fibre optic board Interface board for fibre-based RS485 connection
Fibre optic board + IRIG-B Interface board for fibre-based RS485 connection + demodulated IRIG-B
2nd rear communications board Interface board for RS232 / RS485 connections
2nd rear communications board with IRIG-B input Interface board for RS232 / RS485 + IRIG-B connections
100 MHz Ethernet board Standard 100 MHz Ethernet board for LAN connection (fibre + copper)
100 MHz Ethernet board with modulated IRIG-B Standard 100 MHz Ethernet board (fibre / copper) + modulated IRIG-B
100 MHz Ethernet board with demodulated IRIG-B Standard 100 MHz Ethernet board (fibre / copper)+ demodulated IRIG-B
Redundant Ethernet SHP + modulated IRIG-B Redundant SHP Ethernet board (2 fibre ports) + modulated IRIG-B input
Redundant Ethernet SHP + demodulated IRIG-B Redundant SHP Ethernet board (2 fibre ports) + demodulated IRIG-B input
Redundant Ethernet RSTP + modulated IRIG-B Redundant RSTP Ethernet board (2 fibre ports) + modulated IRIG-B input
Redundant Ethernet RSTP + demodulated IRIG-B Redundant RSTP Ethernet board (2 fibre ports) + demodulated IRIG-B input
Redundant Ethernet DHP + modulated IRIG-B Redundant DHP Ethernet board (2 fibre ports) + modulated IRIG-B input
Redundant Ethernet DHP + demodulated IRIG-B Redundant DHP Ethernet board (2 fibre ports) + demodulated IRIG-B input
Redundant Ethernet PRP + modulated IRIG-B Redundant PRP Ethernet board (2 fibre ports) + modulated IRIG-B input
Redundant Ethernet PRP + demodulated IRIG-B Redundant PRP Ethernet board (2 fibre ports) + demodulated IRIG-B input
Redundant Ethernet HSR + modulated IRIG-B Redundant HSR Ethernet board (2 fibre ports) + modulated IRIG-B input
Redundant Ethernet HSR + demodulated IRIG-B Redundant HSR Ethernet board (2 fibre ports) + demodulated IRIG-B input
Output relay output board (8 outputs) Standard output relay board with 8 outputs
Chapter 3 - Hardware Design P64x
32 P64x-TM-EN-1.3
