Step 17l: Remove the airflow baffle from the server module
The airflow baffle is the large black plastic piece shown in the figure below.
To remove the airflow baffle from the server module, while holding the
baffle by the two raised sections, lift the baffle out of the server module.
Step 17m: Remove the memory cards from the server module
The server module contains 16 memory cards. You need to remove them all
from the module.
Chapter 4: Refurbishing an HCP S30 Node
103
HCP S Series Node Refurbishment
Step 17: Unrack, disassemble, and pack the server modules
