9.
Conditional: Insert the inner enclosure rails into the outer rails (see
page 126)
10.
Pack the enclosure (see page 127)
Step 18a (conditional): Prepare the enclosure carton
For an enclosure that was returned racked, you need to prepare the
enclosure carton before you remove the enclosure from the rack.
To prepare the enclosure carton:
1. Remove the four clips on each of the two opposite ends of the carton. To
remove a clip, while squeezing the tabs on the clip, pull the clip out of
the carton.
2. Lift the top off the carton.
3. Remove any packing materials from inside the carton and set them
aside. These should include foam packing pieces, two straps for lifting
the enclosure, the box for the enclosure mounting rails, the box for the
front panel and light pipe assembly, and the enclosure accessory box.
4. Lift the sides off the bottom of the carton.
5. On the bottom of the carton, position the foam packing pieces that go
under the enclosure so that the enclosure can be correctly seated on
them.
Step 18b (conditional): Remove the upgrade-kit drives from the
enclosure
If the enclosure includes upgrade-kit drives, you need to remove the 28
upgrade-kit drives from the enclosure. After removing the drives, you need
to insert four empty drive placeholders.
Chapter 4: Refurbishing an HCP S30 Node
115
HCP S Series Node Refurbishment
Step 18: Unrack and pack the enclosures
