Servo Drive Configuration E1 Series Servo Drive Thunder Software Operation Manual
4-52 HIWIN MIKROSYSTEM CORP.
4.4.2.3 User-defined parameters
Users can define non-Pt parameters list. Refer to the following table for the functions.
Table 4.4.2.3.1
Delete selected parameter
Delete selected parameter
Save parameter list as a file
Save parameter list as a file
Load parameters from file
Load parameters from file
◼ Add new parameter
1. Click “Add new parameter” icon to open parameters adding window.
Figure 4.4.2.3.1
2. Key in the parameter name to be added.
Figure 4.4.2.3.2
3. Optionally add the description and press Enter key on the keyboard.
To Next Page
