E1 Series Servo Drive Thunder Software Operation Manual Start Thunder
HIWIN MIKROSYSTEM CORP. 3-11
3. After entering new axis name Z, press Enter key on the keyboard to complete the modification.
Figure 3.2.3.3.3
3.2.4 Off-line mode
Users can load servo drive parameters file (*.prm) on off-line mode to observe all parameters. Before using
the function, ensure the servo drive parameters file (*.prm) to be observed has been saved as a file. Refer
to section 4.4.3 for the details about loading servo drive parameters file (*.prm).
Off-line mode only supports parameters viewing; it does not support parameters modifying.
Therefore, it will be ineffective if users modify parameters on off-line mode.
Follow the procedure below to enter off-line mode.
1. Select Off-line (View only) in Config. interface.
Figure 3.2.4.1
