Advanced Functions E1 Series Servo Drive Thunder Software Operation Manual
9-42 HIWIN MIKROSYSTEM CORP.
MD12UE01-2012
setting
(3)
Calculation results
Display results and simulated trends.
section 9.8.4
(4)
Save / Load
Save and load parameters.
section 9.8.5
9.8.2 Motor parameters setting
Follow the procedure below to complete motor parameters setting.
1. Select Tools in the menu bar and click Dynamic brake resistor wizard to open “Dynamic brake
resistor wizard” window.
Figure 9.8.2.1
2. Users can select the desired method based on requirement. For example, automatically fill in the
connected motor parameters, read motor parameters from servo drive’s memory or define motor
parameters on their own.
