E1 Series Servo Drive Thunder Software Operation Manual Servo Drive Configuration
HIWIN MIKROSYSTEM CORP. 4-3
4.1 Brief introduction
All the basic setting procedures of using servo drive are introduced in this chapter. For the detailed
descriptions of servo drive, please refer to “E1 Series Servo Drive User Manual”.
Pre-configuration function
Before servo drive configuration, users can select servo motor type, encoder type and the usage of ESC.
Configuration Wizard
Through step-by-step interface, users can easily set and view servo drive’s important parameters.
Configuration Wizard makes the process of setting necessary parameters become very easy, and it is also
the procedure must be completed during the process of operating servo drive.
Parameters Setup
Based on the classified servo drive Pt parameters list, users can set or compare the Pt parameters different
from factory default values. Besides, users can create, edit, save and load personalized parameters list.
I/O configuration
Users can configure servo drive’s digital input signals and digital output signals.
Phase initialization setup
Users can perform servo motor’s electrical angle positioning with step-by-step phase initialization setup.
