E1 Series Servo Drive Thunder Software Operation Manual Servo Drive Configuration
HIWIN MIKROSYSTEM CORP. 4-63
4.4.4 Send the parameters to servo drive
There are two kinds of servo drive parameters, immediately effective and non-immediately effective. To
make non-immediately effective parameters be effective, users must send them to servo drive and power
cycle servo drive. When the parameters are sent to servo drive, it indicates they are saved to servo drive’s
memory. Even if users power off the servo drive, the parameters setting will not disappear.
◆ To avoid unexpected actions, ensure the motor is disabled and remains static before execution.
Follow the procedure below to send the parameters to servo drive.
1. Click “Save to drive” icon in the toolbar.
Figure 4.4.4.1
2. Click Save to save the parameters data to servo drive’s memory. When it is done, the message
window will show Save RAM to flash ended successfully.
To Next Page
