HP ProLiant DL580 Generation 2 User Manual

Connectors, LEDs, and Switches
Table 4-17: Single-Board Mirrored Memory LEDs
Item Description Indicator Status
Off DIMM is not installed.
Green DIMM is installed.
Amber Memory error has occurred on this
DIMM.
1-4
and
10-13
DIMM 1-8 status
Flashing amber Configuration error has occurred.
Off Memory board is offline.
Green Memory board is online.
Flashing green Memory board is busy.
6 Memory status
Amber Memory error has occurred on this
memory board.
7 Ready to Hot Plug Off Do not remove memory board; single-
board mirrored memory does not
support hot-plug capability.
Off Memory board is not configured for
mirrored memory.
Green Single-board mirrored memory is
functioning properly.
9 Mirroring status
Amber Memory error has occurred and
system has failed over to the mirrored
bank.
All LEDs Off Memory board is not seated properly
or locking switch is not engaged;
memory board can be removed
safely.
Flashing amber
CAUTION: Memory board is in use;
relock it immediately
4-20 HP ProLiant DL580 Generation 2 Server Maintenance and Service Guide

HP ProLiant DL580 Generation 2 Specifications

General

Processor Socket	Socket 604
Storage Controller	Integrated Smart Array 6i Controller
Storage	SAS
Network	Integrated Dual Gigabit NICs
RAID Support	RAID 0, 1, 5
Expansion Slots	6 PCI-X slots
Power Supply	Redundant Power Supplies
Form Factor	4U Rack
Management	HP Integrated Lights-Out (iLO)
Operating System Support	Windows Server, Linux
Processor	Intel Xeon (up to 4 processors)
Drive Bays	Up to 6 hot-plug SCSI or SAS drives
