HP ProLiant DL580 Generation 2 User Manual

Connectors, LEDs, and Switches
Rear Unit Identification LED Switch
The rear unit identification LED switch offers a visual reference for service personnel.
Figure 4-21 illustrates where the rear UID switch is located.
Figure 4-21: Rear Unit Identification LED switch
The rear unit identification LED switch (1) indicates the following conditions:
•
•
Blue = The switch is activated.
Off = The switch is deactivated.
HP ProLiant DL580 Generation 2 Server Maintenance and Service Guide 4-29

HP ProLiant DL580 Generation 2 Specifications

General

Processor Socket	Socket 604
Storage Controller	Integrated Smart Array 6i Controller
Storage	SAS
Network	Integrated Dual Gigabit NICs
RAID Support	RAID 0, 1, 5
Expansion Slots	6 PCI-X slots
Power Supply	Redundant Power Supplies
Form Factor	4U Rack
Management	HP Integrated Lights-Out (iLO)
Operating System Support	Windows Server, Linux
Processor	Intel Xeon (up to 4 processors)
Drive Bays	Up to 6 hot-plug SCSI or SAS drives
