Removal and Replacement Procedures
Table 2-4: Online Spare Memory LEDs
Item Description Indicator Status
Off Memory board is offline.
Green Memory board is online.
Flashing
green
Memory board is busy.
6 Memory
Status
Amber Memory error has occurred on this memory board.
Off Memory board is not configured for online spare
memory.
Green Online spare memory is functioning properly.
8 Online Spare
Status
Amber Memory error has occurred and system has failed over
to the online spare bank.
7 Ready to
Hot Plug
Off Do not remove memory board. Online spare memory
does not support hot-plug capability.
Off Bank is not configured as an online spare bank.
Green Bank is configured as an online spare bank.
5 Online Spare
text
Flashing
green
Failure has occurred and online spare bank is active.
Off DIMM is not installed.
Green DIMM is installed.
Amber Memory error has occurred on this DIMM.
1-4
and
10-13
DIMMs 1-8
status
Flashing
amber
Configuration error has occurred.
All LEDs Flashing
amber
CAUTION: Memory board is in use; relock it
immediately.
HP ProLiant DL580 Generation 2 Server Maintenance and Service Guide 2-19
