HP ProLiant DL580 Generation 2 User Manual

Connectors, LEDs, and Switches
Table 4-18: Hot-Plug Mirrored Memory LEDs
Item Description Indicator Status
Off DIMM is not installed.
Green DIMM is installed.
Amber Memory error has occurred on this
DIMM.
1-4
and
10-13
DIMM 1-8 status
Flashing amber Configuration error has occurred.
Off Memory board is offline.
Green Memory board is online.
Flashing green Memory board is busy.
6 Memory status
Amber Memory error has occurred on this
memory board.
Off Do not remove memory board; memory
board is not configured for hot-plug
removal.
7 Ready to Hot Plug
Green OK to remove memory board –system is
configured for hot-plug mirrored
memory.
Off Memory board is not configured for
mirrored memory.
Green Hot-plug mirrored memory is functioning
properly.
9 Mirroring status
Amber Memory error has occurred and system
has failed over to the mirrored board.
All LEDs Off Memory board is not seated properly or
locking switch is not engaged; memory
board can be removed safely.
Flashing amber
CAUTION: Memory board is in use;
relock it immediately.
HP ProLiant DL580 Generation 2 Server Maintenance and Service Guide 4-21
