INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Function parameter list
-166-
Function
code
Name
Description
Default
Modify
P03.09
Current-loop
proportional
coefficient P
Note:
 The two function codes impact the dynamic
response speed and control accuracy of the
system. Generally, you do not need to
modify the two function codes.
 Applicable to SVC mode 0 (P00.00=0).
 The values of the two function codes are
updated automatically after SM parameter
autotuning is completed.
Setting range: 0–65535
1000
○
P03.10
Current-loop
integral coefficient I
1000
○
P03.11
Torque setting
method
0–1: Keypad (P03.12)
2: AI1 (100% corresponding to triple the motor
rated current)
3: AI2
4: AI3 (same as the above)
5: Pulse frequency HDIA
6: Multi-step torque
7: Modbus communication
8: PROFIBUS/CANopen communication
9: Ethernet communication
10: Reserved
11: PROFINET communication
12–17: Reserved
18: Keypad (for small power models)
0
○
P03.12
Torque set through
keypad
-300.0%–300.0% (of the motor rated current)
20.0%
○
P03.13
Torque reference
filter time
0.000–10.000s
0.010s
○
P03.14
Setting source of
forward rotation
upper-limit
frequency in torque
control
0: Keypad (P03.16)
1: AI1 (100% corresponding to the max.
frequency)
2: AI2 (same as the above)
3: AI3 (same as the above)
4: Pulse frequency HDIA (same as the above)
5: Multi-step setting (same as the above)
6: Modbus communication (same as the above)
7: PROFIBUS/CANopen communication (same
as the above)
0
○
