KEB F6 User Manual

Parameter Descriptions
© 2024 KEB America, Inc.
115
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
-
RW
Mode
-
0
2
-
-
2
Basic
Amplitude Modulation
0
-
-
-
-
-
-
di/dt (Five Step)
1
Auto Select
2
LM30 Motor Control
This parameter activates various controllers in the drive. Multiple options may be
selected, in which the NUM value is the sum of the options selected.
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
-
Motor Model
-
0
31
-
-
2
Basic
OFF
0
-
-
-
-
-
-
Motor Model On
1
Vmax regulation
-
OFF
0
Vmax Regulation
2
Flux Control
-
OFF
0
Flux Control
4
Flux Proofing
-
OFF
0
Flux Proofing
8
Zero spd model
-
OFF
0
Zero spd model
16
-
RW
Motor Model
-
0
3
-
-
2
Basic
OFF
0
-
-
-
-
-
-
Motor Model On
1
Vmax regulation
-
OFF
0
Vmax Regulation
2
Table 16. LM30 Motor control settings
Setting
Description
Motor Model
Turns on motor model. The drive will automatically activate the
motor model after the LL01 Motor Tuning has been completed
successfully.
Vmax Regulation
 Refer to LM31 for further details.
Flux Control
Activates flux control. This setting only applies to induction
motors. The drive will automatically activate the flux control after
the LM01 Motor Tune has been completed successfully.
Flux Proofing
Ensures sufficient flux build up before activating drive on or brake
control outputs. This setting only applies to Induction motors.
Zero Speed
Model
Keeps the motor model active at zero speed.
Default* = Vmax Regulation (2)
* After a LL01 Motor Tuning has been performed, the Motor Model will be turned on and for
Induction motors, Flux Control will also be turned on.
