KEB F6 User Manual

Safety Module
© 2024 KEB America, Inc.
35
3.2 Supplemental Safety Documentation
The certification of the safety module is valid in conjunction with these operating
conditions, installation requirements, and precautions described in this manual as well as
the Installation manual, the general programming manual, and the general manual for the
safety module. Especially relevant is the description of the functionality of the safety
manual. Therefore, it is necessary that persons responsible for the system safety have
access to all the instruction manuals and furthermore understand the requirements
documented within. A Link to supplemental documentation can be found below.
KEB Safety Module 5 documentation.
https://www.keb.de/fileadmin/media/Manuals/dr/ma_dr_safety-
typ5-20191137_en.pdf
3.3 Description of the Safety I/O
3.3.1 Terminal X2B
Table 2. Assignment of terminal X2B
PIN
Name
Function
1
STO1 channel 1
Function1- inputs
2
STO1 channel 2
3
SBC/STO2 channel 1
Function2- inputs
4
SBC/STO2 channel 2
5
No Function
Function3- inputs
6
No Function
7
STO Confirmation
Output1
8
SBC Confirmation
Output2
The voltages of all inputs and outputs refer to the 0V of the control board. The pin
assignment of the control terminals is described in the respective manual of the F6.
