8.5.2 X3B Encoder Output / Input 2
• 
• Parameters LE32...34 and 36 correspond to encoder interface 2, X3B as an
input.
Parameter LE35 corresponds to encoder interface 2, X3B as an output.
LE31 Encoder 2 Interface
This parameter selects the type of encoder feedback and function (input or output) for
X3B.
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
Encoder Type
-
0
23
-
-
0
Basic
No encoder
0
-
-
-
-
-
-
A-B swapped
1
Reserved
2
Reserved
3
Reserved
4
Reserved
5
Reserved
6
Reserved
7
Reserved
8
Reserved
9
Reserved
10
Reserved
11
Reserved
12
Reserved
13
Reserved
14
Reserved
15
TTL Encoder Emulation
16
Reserved
17
Reserved
18
Reserved
19
Reserved
20
Reserved
21
Reserved
22
Reserved
23
LE32 Encoder 2 Pulse Number
This defines the encoder PPR for the second encoder interface. It is valid both as an
input and as an output.
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
1
16384
INC
-
1024
Basic
