Parameter Descriptions
© 2024 KEB America, Inc.
223
8.15 Field Bus Parameters (FB)
8.15.1 Processed PDI Data
After the raw PDI Data (FB34-37) has been received from the controller, it may be
masked or scaled (FB05-09), depending on which function (FB01-04: Control Word,
Speed, Pre-torque, Target Position) the data is mapped to via the PDI Map Assignments
(FB17-20). The PDI Map Assignments will be chosen according to the order of each

FB01 Field Bus Control Word
Read-only display of processed field bus control word in hexadecimal.
FB01 = PDI Data (Control Word) AND FB05 Field Bus Control Word Mask.
Refer to LI15 Direction Selection Inputs, pg. 97 setting on how the hardware and
software inputs are ANDed or ORed.
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RO
RO
Enable
-
0
65535
-
-
0
Basic
0
0
-
-
-
-
-
-
EN
1
Reset
-
0
0
RST
2
Up
-
0
0
UP
4
Down
-
0
0
DWN
8
Bin Speed 1 or Bin Pos 1
-
0
0
BIN1
16
Bin Speed 2 or Bin Pos 2
-
0
0
BIN2
32
Bin Speed 3 or Bin Pos 3
-
0
0
BIN3
64
Reserved or Bin Pos 4
-
0
0
BIN4
128
Reserved or Bin Pos 5
-
0
0
BIN5
256
Fb Special Function 1
-
0
0
SF1
512
Fb Special Function 2
-
0
0
SF2
1024
Fb Special Function 3
-
0
0
SF3
2048
Fb Special Function 4
-
