KEB F6 User Manual

Parameter Descriptions
84
© 2024 KEB America, Inc.
US04 Control Type
This parameter selects the type of speed selection and rotation setting.
Motor Type
Range
Units
Default
Pass
Level
Ind.
Ind.
Min.
Max.
Imp.
Met.
RW
RW
0
6
-
-
1
Basic
Table 10. US04 Control type settings
Setting:
Description:
NUM
Digital Speed Selection
Five digital inputs select up to five different
speeds.
0
Binary Speed Selection
Three digital, binary-coded inputs select up to
seven different speeds.
1
Absolute Analog Speed
0...10V = 0...Contract Speed
Direction by digital inputs
2
Bi-polar Analog Speed
0...±10V = 0...±Contract Speed
Direction by polarity, digital input for start
3
Serial Speed DIN66019,
Service 49
Service 49 = 4x16-bit serial communication.
Speed profile and control inputs via serial
communication. Hardware enable required.
4
Serial Speed DIN66019,
Service 50
Service 50=2x16-bit+1x32-bit+1x32-bit AUX R/W
Speed profile and control inputs via serial
communication. Hardware enable required.
5
Serial Binary Speed,
DIN66019 Service 50
Service 50=2x16-bit+1x32-bit+1x32-bit AUX R/W
The speed selection for Serial Binary Speed is
done through the control-word bits 4, 5, and 6
(Bin. Speed 1 - Bin. Speed 3). Hardware enable
required.
6
CiA417
This setting is for using CAN Open Elevator
functionality; see CAN Open Elevator
supplemental manual 00F5LUZ-KCAN for
description and implementation.
7
• Digital inputs for speed and direction can be programmed to I1...I6, I8 with
LI04-11, where I1>I2>...I8 for speed inputs.
• Logic tables for input-selected speed control are determined by LI03 and or
with LI16.
• LI15 determines whether digital inputs and/or Control Word are used as
direction signal for serial speed control modes.
 See section Control Sequence (All Services), pg. 176 for signal sequencing.
For more speed selection and rotation setting information,  refer to the Method of
Control chapter, pg. 47.
