KEB F6 User Manual

Parameter Descriptions
198
© 2024 KEB America, Inc.
DG02 Inverter Status
DG02 is read from the inverter status. The inverter status is also updated when drive and
LIFT faults occur.
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RO
RO
0
65535
-
-
0
Basic
Table 32. F5 Output status
Description
Value
no operation
0
ERROR Over Voltage
1
ERROR Under Voltage
2
ERROR Input Phase Failure
3
ERROR Over Current
4
ERROR Output Phase Fail.
5
ERROR Overheat Internal
6
no ERROR Overheat Int.
7
ERROR Overheat Pwr.Mod.
8
ERROR Motor Overheat
9
no ERROR Motor Overheat
11
ERROR Power Unit
12
power unit not ready
13
ERROR Charge Relay Open
15
ERROR Overload
16
no ERROR Overload
17
ERROR HSP5 Serial Com.
18
ERROR Overload Low Speed
19
no ERROR Overload Low Speed
20
ERROR bus synchronization
23
ERROR Max. Acceleration
24
ERROR speed ctrl. lim
25
ERROR motor protection
30
ERROR external fault
31
ERROR encoder 1
32
ERROR encoder 2
34
ERROR encoder interface
35
no E. overheat pow.mod.
36
ERROR set
39
ERROR soft.limit for.
44
ERROR soft.limit rev.
45
ERROR prot. rot. for.
46
ERROR prot. rot. rev.
47
ERROR pow.unit code inv.
49
ERROR power unit changed
50
Description
Value
ERROR driver relay
51
ERROR encoder card
52
ERROR input error detect
53
ERROR counter overrun 1
54
ERROR counter overrun 2
55
ERROR low motor current
56
ERROR initialisation MFC
57
ERROR Overspeed
58
ERROR encoder card changed
59
ERROR calc. motor data
60
up acceleration
64
up deceleration
65
up constant speed
66
down acceleration
67
down deceleration
68
down constant speed
69
No direction selected
70
stall
71
LA stop
72
Ld stop
73
speed search
74
DC brake
75
base block
76
low speed / DC brake
77
power off
78
quick stop
79
hardware current limit
80
search for ref.active
81
calculate motor data
82
positioning
83
low speed / power off
84
closing brake
85
opening brake
86
ABN.STOP overheat int.
87
no A. overheat pow.mod.
88
