KEB F6 User Manual

Parameter Descriptions
228
© 2024 KEB America, Inc.
8.15.4 Process Data Output Addresses
These are the mappings of diagnostic parameter hex addresses for Process Data Out.
For example, FB13 PDO1 = 1182h = DG02 Inverter Status. These parameters have the
same structure as FB17-20; refer to these parameters below for further description.
The defaults are established such that:
Table 36. Process data output defaults
US04 Control Type, DIN66019
PDO
Service 49 (4)
Service 50 (5)
Service 50
Serial Binary (6)
PDO1
(1182h)
DG02 Inverter Status
(1182h)
DG02 Inverter Status
(1182h)
DG02 Inverter Status
PDO2
(11B2h)
DG50 Elevator Speed
(11CDh)
DG77 Calculated
Elevator Speed
(11CDh)
DG77 Calculated
Elevator Speed
PDO3
(1185h)
DG05 Actual Torque
(118Bh)
DG11 Output Status
(118Bh)
DG11 Output Status
PDO4
(1186h)
DG06 Motor Current
(11B3h)
DG51 Mode
(11B3h)
DG51 Mode
FB13 PDO1 Map Assignment
Hexadecimal address of diagnostics parameter mapped as Process Data Output 1.
 Refer to the Diagnostics Parameters (DG) section.
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
See Parameter Description
-
0
73
-
-
1
Basic
FB14 PD02 Map Assignment
Hexadecimal address of diagnostics parameter mapped as Process Data Output 2.
 Refer to the Diagnostics Parameters (DG) section.
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
See Parameter Description
-
0
73
-
-
2
Basic
FB15 PDO3 Map Assignment
Hexadecimal address of diagnostics parameter mapped as Process Data Output 3.
 Refer to the Diagnostics Parameters (DG) section.
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
See Parameter Description
-
0
73
-
-
3
Basic
