KEB F6 User Manual

Parameter Descriptions
238
© 2024 KEB America, Inc.
TS01 NTSD Mode
The NTSD Mode defines the assignment of the NTS inputs to the NTSD speed
thresholds.
The NTSD inputs can be assigned in parameters LI04 - LI11 to the corresponding
hardware inputs X2A1-8, or by FB21-27 to the corresponding serial Control Word special
function bits 9-15.
NTSD
NUM
NTS1 (Normal Terminal Slowdown 1)
29
NTS2 (Normal Terminal Slowdown 1)
30
NTS3 (Normal Terminal Slowdown 1)
31
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
NTSD Mode
-
0
4
-
-
0
Basic
External
0
-
-
-
-
-
-
Threshold 1
1
Threshold 2, Binary Encoded
2
Threshold 3, Binary Encoded
3
One switch per Threshold
4
Table 39. TS01 NTSD mode settings
Setting
Description
External
No function.
Threshold 1*
Single NTSD threshold.
Threshold 2, Binary
Encoded*
Two NTSD thresholds, binary coded from two inputs.
Threshold 3, Binary
Encoded*
Three NTSD thresholds, binary coded from two inputs.
One switch per threshold***
Up to three NTSD thresholds, each assigned to an individual
input.
* If any NTS input is not active at the beginning of a run, the drive will enter normal
acceleration until the programmed NTS threshold speed is reached then slow down to
the NTSD target speed.
*** If any NTS input is not active at the start a NTS Input Failure fault will be triggered.
The following tables indicate the NTSD speed threshold according to the NTSD mode
and input states.
Threshold 1, NUM = 1
NTSD Input 2
NTSD Input 1
Function
x
1
Normal operation
x
0
Evaluate NTSD 1 Speed
