KEB F6 User Manual

Parameter Descriptions
© 2024 KEB America, Inc.
189
8.13 Outputs Parameters (LO)
LO01 Output Inversion
Allows the logic of the digital and relay outputs to be inverted.
The brake output cannot be inverted!
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
Output Inversion
-
0
15
-
-
0
Basic
None
0
-
-
-
-
-
-
/O1
1
/O2
2
/O1 + /O2
3
/RLY1
4
/RLY1 + /O1
5
/RLY1 + /O2
6
/RLY1 + /O1 + /O2
7
/OSW
8
/OSW + /O1
9
/OSW + /O2
10
/OSW+ /O1 + /O2
11
/OSW+ /RLY1
12
/OSW + /RLY1 + /O1
13
/OSW + /RLY1 + /O2
14
/OSW + /RLY1 + /O1+ /O2
15
LO05-LO15 Output Functions:
Table 28. LO05-LO15 Output function settings
Setting
Description
NUM
Off
Output is disabled.
0
Fault*
Output is set when there is a drive fault.
1
Drive Ready*
Output is set when there are no drive faults and the drive is
ready for operation.
2
Fault (1) and Drive Ready (2) cannot be used together!
At Speed
Output is set when there is no speed deviation between
actual and command values, according to the LX14 Speed
Difference.
5
High Speed*
Output is set whenever the speed is greater than two times
LS01 Leveling Speed.
6
Deceleration
Active*
Output is set when decel is active and the speed drops below
LX16 Decel Confirmation Speed.
7
