KEB F6 User Manual

Parameter Descriptions
216
© 2024 KEB America, Inc.
DG80 Output Status and Easy Direction
Displays the status of the outputs and easy direction function.
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RO
RO
Output Status
-
0
63
-
-
0
Basic
O1
1
-
-
-
-
-
-
Output Status
-
O2
2
Output Status
-
RLY1
4
Easy Dir. Rdy
-
Easy Dir. Not Rdy
0
Easy Dir. Rdy
16
Easy Direction
-
Easy Dir. Up
0
Easy Dir. Down
32
DG90 System Status
Reads the top of the event log to get the most recent status of the system.
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RO
RO
0
65535
-
-
0
Basic
Table 34. DG90 Fault Status Specifications
Sub-Definition
Value
No Fault
0
Fault
32768
Table 35. DG90 System status specifications
Description
Value
Empty
0
Power On
1
DC bus discharged
2
Charging DC bus
3
Mains engaged
4
Charge request dropped
5
Disconnected from mains
6
Reconnect delay active
7
Reconnect delay complete
8
Mains fault - no L1 L2 L3
9
Mains fault - no L1
10
Mains fault - no L2
11
Description
Value
Mains fault - no L3
12
Charge relay fault
13
Charging DC bus timeout
14
Mains relay fault
15
Mains relay AUX fault
16
DC bus high fault
17
DC bus low fault
18
Resetting charge fault
19
Resetting charge state machine
20
Reset Mains fault
21
Charge reserved
22-24
Motor Tune activated
25
