KEB F6 User Manual

Parameter Descriptions
78
© 2024 KEB America, Inc.
8 Parameter Descriptions
The programming menu is where all manual parameter adjustments are made and can
be accessed at HOME > PROG (F3).
8.1 Parameter Groups
The Parameter menu contains the following groups:
User Definition (UD): UD01, UD04
This group exists in F5 and F6 devices and provides the user password among other
functions.
Device Info (DE): 
These parameters provide information about the Elevator inverter such as software
version, hardware version, power stage, etc. Additionally, there are several key
parameters which are required to support testing in the production department.
Configuration Handling Parameters (CH): CH01...CH15
These settings allow a user to save parameters and default to OEM settings.
Basic Setup Parameters (US): US02...US06
These parameters provide the essential information needed to configure the drive: Motor
type, control type, and contract speed.
Input Parameters (LI): LI01...LI60
These parameters define the logic of the inputs and assign control functionality to the
digital inputs.
Motor Data Parameters (LM): LM01...LM33
These parameters define and display all relevant motor values and motor protection
settings.
Encoder Data Parameters (LE): LE01...LE36
These parameters define the settings and scaling of the drive encoders.
Machine Data Parameters (LN): LN01...LN05
These parameters define the machine data: Sheave diameter, roping ratio, and rated
load values.
Speed Profile Parameters (LS): LS00...LS55
These parameters adjust the speed, acceleration, and jerk values across the elevator run
profile.
Tune Parameters (LL): LL01...LL18
These parameters contain the automatic tuning parameters, system inertia, motor data,
and motor pole positions.
Control Setting Parameters (LC): LC01...LC44
These parameters contain advanced adjustment parameters which affect the motor
gains, system inertia gains, pre-torque, etc.
Timer Parameters (LT): LT01...LT31
These parameters adjust brake and drive signaling timers.
Special Functions Parameters (LX): LX01...LX25
These parameters allow advanced adjustment of the drive and facilitate function tests of
drive components.
