KEB F6 User Manual

Parameter Descriptions
© 2024 KEB America, Inc.
97
LI10 Input 7 Function
LI04-11: Digital Inputs
LI04...LI11 correspond to inputs I1...I8. Each input is programmable with one of the input
functions listed for LI04.
Functionality
Input 7 corresponds to digital control terminal I7, X2A7.
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
0
33
-
-
0
Basic
LI11 Input 8 Function
LI04-11: Digital Inputs
LI04...LI11 correspond to inputs I1...I8. Each input is programmable with one of the input
functions listed for LI04.
Functionality
Input 8 corresponds to digital control terminal I8, X2A8.
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
0
33
-
-
16
Basic
LI15 Direction Selection Inputs
Sets the function of inputs programmed as up and down according to US04 Control Type.
In addition, the brake control output condition can be assigned to direction or speed
inputs. Direction selection and brake function options can be selected in combination.
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
0
8
-
-
0
Basic
Table 13. LI15 Direction selection input settings
Direction Selection
Setting
Description
NUM
Up & Down
Inputs
When Up and Down functions are programmed to digital
inputs (LI04-11), if either the digital input is selected OR the
direction bit in the Control Word (serial speed control, FB01
Field Bus Control Word), then the direction bit will be set.
Up/Down inputs control direction or start. If both Up and

occur unless in UPS Operation mode; refer to LI04 UPS
Operation for details*
0
