Lenze i55 Series User Manual

Parameter Name / value range / [default seng] Info
0x1018:002 Identy object: Product ID
•
Read only
•
From version 02.00
Display of the product code of the inverter.
0x1018:003 Identy object: Revision number
•
Read only
•
From version 02.00
Display of the main and subversion of the rmware.
0x1018:004 Identy object: Serial number
•
Read only
•
From version 02.00
Display of the serial number of the inverter.
0x2362:004
(P511.04)
Acve EtherCAT sengs: Device idener
(EtherCAT diag.: Device ident.)
•
Read only
•
From version 02.00
Display of the clear device address in the network which is dened via
rotary encoder switch or object 0x2361:004 (P510.04).
0x2362:006
(P511.06)
Acve EtherCAT sengs: Staon address
(EtherCAT diag.: Staon address)
•
Read only
•
From version 02.00
Display of the acve staon address.
0x2362:007
(P511.07)
Acve EtherCAT sengs: Tx length
(EtherCAT diag.: Tx length)
•
Read only
•
From version 02.00
Display of the length of the transmied cyclic data in bytes.
0x2362:008
(P511.08)
Acve EtherCAT sengs: Rx length
(EtherCAT diag.: Rx length)
•
Read only
•
From version 02.00
Display of the length of the received cyclic data in bytes.
0x2368
(P516.00)
EtherCAT status
(EtherCAT status)
•
Read only
•
From version 02.00
Display of the current network status.
1 Inialisaon Network inialisaon is acve.
•
No PDO/SDO transmission.
•
Device idencaon is possible by network scan.
2 Pre-Operaonal The network is acve.
•
SDO transmission (CoE communicaon via mailbox) is possible.
•
No PDO transmission.
3 Bootstrap Firmware update acve.
•
For the rmware update, the FoE protocol is used.
•
No PDO transmission.
4 Safe-Operaonal SDO transmission (CoE communicaon via mailbox) is possible.
PDO transmission:
•
The input data in the process image are updated.
•
The output data from the process image are not transmied.
8 Operaonal Normal operaon
•
PDO/SDO transmission is possible.
•
Network synchronisaon is successful (if used).
0x2369
(P517.00)
EtherCAT error
(EtherCAT error)
•
Read only
•
From version 02.00
Bit coded display of EtherCAT errors.
Related topics
4EtherCAT ^ 383
6.2.4.7 POWERLINK diagnoscs
The following parameters serve to diagnose the POWERLINK interface and the communicaon
via POWERLINK.
Precondions
Control unit (CU) of the inverter is provided with POWERLINK.
Parameter Name / value range / [default seng] Info
0x1000 NMT_DeviceType_U32
•
Read only
CANopen device prole according CANopen specicaon CiA 301/
CiA 402.
Diagnoscs and fault eliminaon
Diagnoscs parameter
Network diagnoscs
128
