Save the »RSLogix™« project and load the conguraon into the PLC (scanner):
1.»RSLogix™«project must be saved.
Click "File" in the upper toolbar and execute the "Save" menu command.
If the project is saved for the rst me, the "Save as" dialog box appears. Here, navigate to a
folder and click "Save".
The conguraon is saved in a le on your PC.
2.Load conguraon into the scanner.
a) Click "Communicaons" in the upper toolbar and execute the "Download" menu com-
mand.
The "Download" dialog box is opened.
b) Click "Download".
The conguraon is loaded into the scanner.
If the download has been completed successfully, »RSLogix™« changes to the online
mode and the I/O-OK eld in the upper le area of the screen is green.
Conguring the network
EtherNet/IP
Process data transfer
336
