• CCWT: ATA plays the CCWT (CO Call Waiting Tone) when an incoming call arrives while the user is
busy with one active call.
• Prompt Tone: ATA plays 'Prompt Tone' instead of dial tone if PIN authentication is enable.
Table 1: (CPTG)
Code Country
Dial Tone Ring Back Tone Busy Tone Error Tone1 Error Tone2
Freq. Cadence Freq. Cadence Freq. Cadence Freq. Cadence Freq. Cadence
Hz second Hz second Hz second Hz second Hz second
01 Australia 425*25 cont. 400*25
0.4on 0.2off
0.4on 2.0off
425
0.375on
0.375off
425
0.375on
0.375off
425 1on 1off
02 Argentina 425 cont. 425 1.0on 4.0 off 425 0.3on 0.2off 425 0.3on 0.4off 425 1on 1off
03 Belgium 425 cont. 425 1.0on 3.0off 425 0.5on 0.5off 425
0.167on
0.167off
425 1on 1off
04 Brazil 425 cont. 425 1.0on 4.0 off 425
0.25on
0.25off
425
0.25on
0.25off
425 1on 1off
05 China 450 cont. 450 1.0on 4.0off 450
0.35
on0.36off
450 0.7on 0.7off 450 1on 1off
06 Egypt 425*50 cont. 425*50 2.0on 1.0off 425*50 1.0on 4.0off 450 0.5on 0.5off 450 1on 1off
07 France 440 cont. 440 1.5on 3.5off 440 0.5on 0.5off 440
0.25on
0.25off
440 1on 1off
08 Germany 425 cont. 425 1.0on 4.0off 425
0.48on
0.48off
425
0.24on
0.24off
425 1on 1off
09 Greece 425
0.2on
0.3off
0.7on
0.8off
425 1.0on 4.0off 425 0.3on 0.3off 425
0.15on
0.15off
425 1on 1off
10 India 400*25 cont. 400*25
0.4on 0.2off
0.4on 2.0off
400
0.75on
0.75off
400
0.25on
0.25off
400 1on 1off
11 Indonesia 425 cont. 425 1.0on 4.0off 425 0.5on 0.5off 425
0.25on
0.25off
425 1on 1off
12 Iran 425 cont. 425 1.0on 4.0off 425 0.5on 0.5off 425
0.25on
0.25off
425 1on 1off
13 Israel 400 cont. 400 1.0on 3.0off 400 0.5on0.5off 400
0.25on
0.25off
400 1on 1off
14 Italy 425 cont. 425 1.0on 4.0off 425 0.5on 0.5off 425 0.2on 0.2off 425 1on 1off
15 Japan 400 cont. 400*20 1.0on 2.0off 400 0.5on 0.5off 400
0.25on
0.25off
400 1on 1off
16 Kenya 425 cont. 425
0.67on 3.0off
1.5on 5.0off
425
0.2on 0.6off
0.2on 0.6off
425 0.2on 0.6off 425 1on 1off
17 Korea 350+440 cont. 440+480 1.0on 2.0off
480+62
0
0.5on 0.5off 480+620 0.3on 0.2off 480+620 1on 1off
18 Malaysia 425 cont. 425
0.4on 0.2off
0.4on 2.0off
425 0.5on 0.5off 425 0.5on 0.25off 425 1on 1off
19 Mexico 425 cont. 425 1.0on 4.0off 425
0.25on
0.25off
425
0.25on
0.25off
425 1on 1off
20
New
Zealand
400 cont. 400+450
0.4on 0.2off
0.4on 2.0off
400 0.5on 0.5off 400
0.25on
0.25off
400 1on 1off
21 Philippines 425 cont. 425+480 1.0on 4.0off
480+62
0
0.5on 0.5off 480+620
0.25on
0.25off
480+620 1on 1off
22 Poland 425 cont. 425 1.0on 4.0off 425 0.5on 0.5off 425 0.5on 0.5off 425 1on 1off
23 Portugal 425 cont. 425 1.0on 5.0off 425 0.5on 0.5off 450 0.33on 1.0off 450 1on 1off
24 Russia 425 cont. 425 0.8on 3.2off 425 0.4on 0.4off 425
0.25on
0.25off
425 1on 1off
25
Saudi
Arabia
425 cont. 425 1.2on 4.6off 425 0.5on 0.5off 425
0.25on
0.25off
425 1on 1off
26 Singapore 425 cont. 425*24
0.4on 0.2off
0.4on 2.0off
425
0.75on
0.75off
425
0.25on
0.25off
425 1on 1off
27 South Africa 400*33 cont. 400*33
0.4on 0.2off
0.4on 2.0off
400 0.5on 0.5off 400
0.25on
0.25off
400 1on 1off
28 Spain 425 cont. 425 1.5on 3.0off 425 0.2on 0.2off 425
0.25on
0.25off
425 1on 1off
