Matrix SETU ATA211 SIP-FXS-FXO User Manual

Matrix SETU ATA211 V1 System Manual 137
• DNS IP address: You should configure this, only if option for 'DNS Server' is selected as 'Static'. By
default it is blank.
• DNS Domain Name: You should configure this, only if option for 'DNS Server' is selected as 'Static'.
Program DNS Name, using 24 characters maximum. The ASCII characters are allowed. By default it is
blank.
Router's Public IP Address:
'Router's Public IP Address' is the public IP Address of the NAT router, behind which the ATA211 is located.
Program this parameter only if 'Use Router's Public IP Address' option is selected for parameter "Source Port IP
Address" programmed in the Web page 'SIP Accounts'. The 'Router's Public IP Address' is also displayed in 'Status'
page. Refer chapters “SIP Accounts” and “Checking the Status”.
By default, it is blank.
MAC Address Setting
ATA211 provides unique MAC address to its WAN port.
ATA211 also facilitates the changing of MAC address at the WAN port. The process of changing the MAC address
of a device is known as MAC Address Cloning. MAC Address Settings can be done as follow:
You can select MAC address from two options:
• MAC Address
• Clone MAC Address.
• MAC Address: If 'MAC Address' is selected, ATA211 will use pre-programmed MAC address as source
MAC address in all Ethernet frames. By default pre-programmed MAC Address is selected.
• Clone MAC Address: Select this if you want ATA211 to use MAC address other then 'MAC address', pre-
programmed. If this option is selected, program the desired MAC address manually. Only Hexadecimal
characters are allowed. By default, it is blank.
To prevent the possible collision and loss of data, do not clone the MAC address which is already used by
other device in the same network.
Enable 100rel?
This parameter is programmed to Enable/disable 100rel SIP extension. It is useful, where it is required to support
reliable transmission of (SIP) provisional responses.
Select 'Yes' if you want the ATA, to use 100rel extension for reliable transmission of SIP (provisional) responses
and to use PRACK (Provisional Acknowledgement). By default, Enable 100rel ? is 'Disabled'.
SIP Timers
ATA211 supports three programmable SIP timers viz. SIP INVITE Timer, SIP Provisional Timer and General
Request Timer.
• SIP INVITE Timer: It is the time for which ATA211 waits for a response from the called party after sending
INVITE message. This timer starts after sending INVITE message to the called party and stops on receipt

Matrix SETU ATA211 SIP-FXS-FXO Specifications

General

Type	SIP-FXS-FXO
FXS Ports	2
FXO Ports	1
Protocol	SIP
Network Interface	10/100 Mbps Ethernet
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Voice Codec	G.711, G.729, G.726
Humidity	Up to 95% RH, Non-condensing

Summary

Introduction

Intended Audience

Identifies the target readers for the system manual.

Organization of this document

Outlines the structure and topics covered in the manual.

Knowing SETU ATA211

The Overview

General description of the ATA211's capabilities and features.

WAN Port

Details the function and connection of the Wide Area Network port.

LAN Port

Explains the function and connection of the Local Area Network port.

FXS Port

Describes the Foreign Exchange Station port for connecting telephones.

FXO Port

Details the Foreign Exchange Office port for PSTN line connection.

LEDs

Explains the meaning of various LEDs indicating device status.

Getting Started

Protecting SETU ATA211

Outlines safety precautions for installation and operation.

Installing SETU ATA211

Provides step-by-step instructions for the initial setup and installation.

Mounting the ATA211 on wall

Describes the procedure for physically mounting the ATA211 unit.

Using SETU ATA211

Making Calls

Explains various methods for initiating outgoing calls.

Receiving Calls

How the ATA211 handles incoming calls.

Managing Calls

Covers features for handling active and held calls.

Call Features

Detailed explanation of supplementary call services.

Configuring SETU ATA211

Admin Password

Instructions for setting and managing the administrator password.

WAN Port

Configuration steps for the Wide Area Network port settings.

LAN Port

Configuration steps for the Local Area Network port settings.

SIP Accounts

Setup and configuration of SIP accounts for VoIP services.

System Parameters

Adjusting general system settings and operational parameters.

Software Upgrade

Reinstate the Default Settings

Default System through Web Jeeves

Steps to reset the system to factory defaults via the web interface.

Default System using SLT command

Procedure to reset the system using a telephone instrument command.

Appendix

Frequently Ask Questions (FAQs)

Answers to common questions regarding the ATA211.

System Commands

Reference for command-line interface operations.
