36 Matrix SETU ATA211 V1 System Manual
Using this feature you can make OG calls using specific trunk. You can select the required trunk (FXO/SIP1/SIP2/
SIP3) by dialing corresponding Access Code and then making call by dialing the number, irrespective of the port set
for 'Outgoing Call Route'.
Making Calls using Speed Dialing
Go OFF-Hook
Dial #9-Index number
Talk
You can dial the number by dialing access code i.e. #9 from FXS, followed by the Index number for that number
where it is configured in the speed dial table.
For more details on configuration of speed dialing, please refer sub-topic “Speed Dialing” in 'Configuring SETU
ATA211'.
Making Peer to Peer Calls
Go OFF-Hook
Dial number stored in P2P table
Talk
Peer to Peer calls are the calls made between two SIP clients without the intervention of a proxy server.
To make Peer to Peer call, you should configure peer to peer table in the Web Jeeves of ATA211. Also, you need to
enable the desired 'SIP Account', in web page 'SIP accounts', which is to be used as P2P trunk (or keep the
registrar server address for the SIP account, as blank).
Peer to Peer application is used by various branch offices of a corporate office and also by the residential user to
communicate with their relatives staying geographically away.
For more details, please refer “Peer-to-Peer Call Application” in 'Installing SETU ATA211' and "Peer to Peer Calls"
in 'Call Features'.
Direct IP Calling: You can make a call from FXS port by dialing 190*1*1*100 for making call to 190.1.1.100. (dot '.'
Should be dialed by using '*').
To avoid delay of Inter Digit Wait timer before the ATA dials the number, you can dial '#' at the end of
dialing digits for the number string while making calls.
