— 3.5 —
Select cutter or roller.
Execute a pattern intended for the
adjustment of the eccentricity.
Execute the eccentricity adjusting
procedure.
Execute a pattern intended for the
adjustment of the
θθ
θθ
θ.
Execute the
θθ
θθ
θ adjusting procedure.
Execute a pattern intended for the
adjustment of the offset.
Execute the offset adjusting procedure.
TOOLS ARE NOT ALIGNED TO EACH OTHER. [TOOL SELECT]
If a plotting tool and a cutter or a plotting tool and a creasing roller fail to finish patterns that lack in
overlapping, the deviation between the tools has to be adjusted.
To adjust the alignment of each tool, use “adjustment of the cutter” and “adjustment of the roller”
among the “TOOL SELECT” functions.
To execute the tool adjusting function, set the speed and acceleration of each tool as described
below. If the speed and acceleration are too high, adjustments cannot be carried out with accuracy.
Speed .................. 20 cm/s
Acceleration ....... 0.1 G
Flowchart of checking and adjusting procedures
Selecting a tool.
(See page 2.14.)
Adjust the eccentricity.
(See pages 3.6 and 3.10.)
Adjust the eccentricity.
(See page 3.14.)
Adjust the θ angle.
(See pages 3.8 and 3.11.)
Adjust the θ angle.
(See page 3.14.)
Adjsut the offset.
(See pages 3.9 and 3.12.)
Adjsut the offset.
(See page 3.14.)
To Next Page
