MIMAKI CF-0912 User Manual

— A.6 —
TOOL SELECT HEAD TOOL PEN, SWIEVEL
HEAD TOOL θ CUTTER 1, θ CUTTER 2
HEAD TOOL ROLLER 1, ROLLER 2, ROLLER 3, ROLLER 4,
R. CUTTER 2
1/4 CONDITION TOOL
SWIEVEL
θ CUTTER 1 ~ 2
θ CUTTER 1 ~ 4
R. CUTTER 1 ~ 2
TEST CUT END, CE
DATA CLEAR END, CE
2/4 SINGLE COPY END, CE
VIEW LOWER RIGHT,
LOWER LEFT
INTERFACE I/F AUTO END, CE
BAUD RATE 1200, 2400, 4800, 9600, 19200 (BPS)
3/4 DATA BITS 7, 8 (bit)
PARITY NO PARITY, EVEN, ODD
STOP BITS 1, 2 (bit)
HANDSHAKE HARDWARE, X CODE, ENQ/ACK, SOFTWARE
SPEED 2, 5, 10, 15, 20, 25, 30, 35,
40, 45, 50 (cm/s)
PRESSURE 20 ~ 200 (g)
ACCELE (ACCELERATION) 0.1 ~ 0.5 (G)
R5 SPEED OFF, 1, 2 (cm/s)
R10 SPEED OFF, 1, 2, 3, 4, 5 (cm/s)
R15 SPEED OFF, 1, 2, 3, 4, 5, 10 (cm/s)
R20 SPEED OFF, 1, 2, 3, 4, 5, 10,
15 (cm/s)
R30 SPEED OFF, 1, 2, 3, 4, 5, 10, 15,
20 (cm/s)
R40 SPEED OFF, 1, 2, 3, 4, 5, 10, 15, 20,
25 (cm/s)
R50 SPEED OFF, 1, 2, 3, 4, 5, 10, 15, 20,
25, 30 (cm/s)
R100 SPEED OFF, 1, 2, 3, 4, 5, 10, 15, 20,
25, 30, 35 (cm/s)
SPEED 2, 5, 10, 15, 20, 25, 30, 35,
40, 45, 50 (cm/s)
PRESSURE 20 ~ 200 (g)
OFFSET 0.00 ~ 2.50 (mm)
ACCELE (ACCELERATION) 0.1 ~ 0.5 (G)
SPEED 2, 5, 10, 15, 20, 25, 30, 35,
40, 45, 50 (cm/s)
PRESSURE 300 ~ 1500 (g)
ACCELE (ACCELERATION) 0.1 ~ 0.5 (G)
FRONT OFFSET 0.00 ~ 2.50 (mm)
END OFFSET 0.00 ~ 2.50 (mm)
UP ANGLE 0 ~ 180 (° )
RING DISTANCE 0.00 ~ 2.50 (mm)
PRESS CORRECTION 0 ~ 500 (g)
VIBRATION 1 ~ 5, or OFF
R5 SPEED OFF, 0,5 (mm/s),
0.1, 0.2, 0.5, 1.0, 2.0 (cm/s)
R10 SPEED OFF, 0.5 (mm/s),
0.1, 0.2, 0.5, 1.0, 2.0 (cm/s)
R15 SPEED OFF, 0.5 (mm/s),
0.1, 0.2, 0.5, 1.0, 2.0 (cm/s)
SPEED 2, 5, 10, 15, 20, 25, 30,
35, 40, 45, 50 (cm/s)
PRESSURE 1000 ~ 5000 (g)
ACCELE (ACCELERATION) 0.1 ~ 0.5 (G)
UP ANGLE 0 ~ 180 (° )
RING DISTANCE 0.00 ~ 2.50 (mm)
PRESS CORRECTION 0 ~ 1000 (g)
PRESSURE (Y) –5000 ~ 5000 (g)
SPEED 2, 5, 10, 15, 20, 25, 30,
35, 40, 45, 50 (cm/s)
PRESSURE 1000 ~ 5000 (g)
ACCELE (ACCELERATION) 0.1 ~ 0.5 (G)
FRONT OFFSET 0.00 ~ 2.50 (mm)
END OFFSET 0.00 ~ 2.50 (mm)
UP ANGLE 0 ~ 180 (° )
RING DISTANCE 0.00 ~ 2.50 (mm)
PRESS CORRECTION 0 ~ 500 (g)
R5 SPEED OFF, 0,5 (mm/s),
0.1, 0.2, 0.5, 1.0, 2.0 (cm/s)
R10 SPEED OFF, 0.5 (mm/s),
0.1, 0.2, 0.5, 1.0, 2.0 (cm/s)
R15 SPEED OFF, 0.5 (mm/s),
0.1, 0.2, 0.5, 1.0, 2.0 (cm/s)
B. LOCAL MENU STRUCTURE
RC-head model

MIMAKI CF-0912 Specifications

General

Brand	MIMAKI
Model	CF-0912
Category	Plotter
Language	English
