MIMAKI CF-0912 User Manual

LOCAL/REMOTE MODES
The operation mode is changed over alternately between the LOCAL mode and the REMOTE
mode every time the
REMOTE
LOCAL
key is pressed.
LOCAL mode and the indication on the LCD
Under LOCAL mode, the head travels, functions of the device are set, and data from the personal
computer are received.
All keys on the operation panel are rendered operative under the LOCAL mode.
Under the LOCAL mode, the following three different kinds of indications are given on the LCD.
LOCAL menu: Function name selecting screen
This screen appears when the power to the device is turned on. The main menu consists of four
pages.
Sub menu 1: Set value inputting screen
This screen appears after a function has been selected on the main menu using the corresponding
function key.
A set value can be input on this screen using function keys.
The asterisk (∗) mark given on the left of the set value indicates that the value is currently valid.
Sub menu 2: Function executing screen
A function is executed on this screen. Functions that can be executed include “test cut,” “data
clear” and “automatic judgment of communication conditions.”
Indicates the function keys to be
used to select the function.
Indicates the page number
of the sub menu.
Indicates the execution key.
Indicates the cancel key.
[ LOCAL ] 1 / 4
TOOL SELECT ———>
CONDITION ———>
TEST CUT ———>
< INTERFACE > 1 / 2
I / F AUTO ———>
BAUD RATE * 9600 >
DATA BITS * 8 >
< TEST CUT > 1 / 1
END KEY to START
CE KEY to CANCEL
Indicates that the device is
under the LOCAL mode.
Indicates the page number
of the main menu.
Indicates the name of function
Indicates the name of
function that has been
selected.
Indicates the function keys to be
used to select the function.
Indicates the name of
function that has been
selected.
