FIXING A WORK
A work can be fixed on the device following one of the two procedures described below.
• Fixing the work with vacuum
•Fixing the work with adhesive tape
• Thickness of works that can be attached on this device should not exceed 20 mm.
Four area marker labels are attached to the cutting panel under the felt mat. The area within
the labels is the maximum effective cutting area in which cutting can be performed. Fix a
work within this area.
Cutting cannot be mechanically performed in any area outside the area marker labels.
Fixing a work that is comparatively light in weight
A work that is comparatively light in weight such as thin coated board or corrugated fiberboard is
vacuum-sucked for the securing.
• If a work is too small to cover all suction holes, cover all the holes with a sheet.
If any of the suction holes is not covered, the suction force will decrease to fail to
secure the work.
1 Place a work on the cutting panel.
Sheet
Sheet
Work
To Next Page
