— A.19 —
F. OPTIONAL ACCESSORIES
Swievel cutter components
Name of product Product No. Specifications Remarks
Swievel cutter holder SPA-0001 One piece of holder without blade
Swievel blade for vinyl sheet SPB-0001 Package of three pieces of blades Common blade for
swievel cutter
Swivel blade for small letters SPB-0003 Package of three pieces of blades
Swievel blade for rubber sheet SPB-0005 Package of three pieces of blades
Swievel blade for reflecting sheet SPB-0006 Package of three pieces of blades
Swievel blade for fluorescent sheet SPB-0007 Package of three pieces of blades
Blade tip adjuster OPT-C0066 Dial type
Reciprocal Relationships
Name of product Product No. Type Remarks
Cutter holder 4N SPA-0053 A100503 For SPB-0013, 0044, 0045, 0046, 0047, 0008 (RC/RT)
Cutter holder 7N SPA-0054 A100504 For SPB-0048 (RC/RT)
Cutter holder RN SPA-0055 A100505 For SPB 0009 (for reflecting sheet) (RC/RT)
Cutter holder JN SPA-0061 A100515 For SPB-0031 (RC/RT)
Cutter holder 10N SPA-0077 A100567 For SPB-0051 (RC/RT)
Creasing roller DN SPA-0056 A100506 Thick (for E corrugated fiberboard) (RC)
Creasing roller CN SPA-0057 A100507 Medium (for coated board) (RC)
Creasing roller PN SPA-0058 A100508 Fine (for coated board) (RC)
Crease plate EN SPA-0067 A100545 For corrugated fiberboard (E board B board) (RC)
Crease plate AN SPA-0103 A100891 For corrugated fiberboard
(A corrugated fiberboard AB corrugated fiberboard) (RC)
Cutter holder 06 SPA-0099 A100887 For SPB-0064. For sponge 20 mm (RT)
Cutter holder 07 SPA-0114 A101211 For SPB-0055, 0065. Until AB corrugated fiberboard (RC)
Cutter holder 2N SPA-0113 A101210 For SPB-0043, 0044, 0045, 0046, 0047, 0008. Up to 2-mm thick
(RC/RT)
Titanium coated blade 45˚ SPB-0008 A100106 SPA-0053 holder use. SPA-0113 use.
Titanium coated both blades SPB-0009 A100128 SPA-0055 holder use
Carbide both blades SPB-0031 A100372 SPA-0061 use
High-speed steel blade 30˚ SPB-0043 A100509 SPA-0053 use. SPA-0113 use.
High-speed steel blade 45˚ SPB-0044 A100510 SPA-0053 use. SPA-0113 use.
Carbide blade 30˚ SPB-0045 A100528 SPA-0053 use. SPA-0113 use.
Carbide blade 45˚ SPB-0046 A100529 SPA-0053 use. SPA-0113 use.
Titanium-coated blade 30˚ã SPB-0047 A100530 SPA-0053 use. SPA-0113 use
High-speed steel blade 30˚ 7 mm SPB-0048 A100531 SPA-0054 use
Carbide design blade 30˚ SPB-0051 A100561 SPA-0077 use
20 mm blade SPB-0055 A100883 Additionally processed Olfa-made commercially available blade
(SK2). For cutting works with a thickness of up to 15 mm.
SPA-011 use.
Carbide blade 17˚ SPB-0065 A101227 For corrugated fiberboard. SPA-0114 use.
Carbide blade 2˚ SPB-0064 A101209 For sponge 20 mm. SPA-0099 use.
Blade tip adjuster (dial) OPT-C0030 A100068 For SPA-0053
Roll hanger OPT-C0120 A100537 under 150, length 1080 or less, weight 30 kg or less
Vacuum unit OPT-C0127 A100556 No filter, single-phase 100 V, 0.51/0.7 kw
(standard supplied blower)
Vacuum unit OPT-C0159 A100660 With filter, 3-phase 200 V, 0.51/0/7 kw
Vacuum unit OPT-C0166 A100884 With filter, 3-phase 200 V, 1.6/2.2 kw
Filter OPT-C0165 A100840 For OPT-C0127 (Standard supplied filter)
Commercially available pen holder SPA-0073 A100563 Supports specific commercially available ballpoint pens
Felt mat Reciprocal cutter blade receiver, 4 types
Filter element SPC-0226 A100851 For blower filter
