— 2.3 —
MODE SET menu
The following explains functions of the [MODE SET] in the LOCAL menu.
Function Description Reference page
COMMAND Commands are set to the MGL-IIc3. Switching
commands on the plotter side is not possible.
UNIT The unit to be used when indicating numerics on the
LCD is specified.
AUTO VIEW A period of time from the completion of cutting
(plotting) to the start of head retraction is specified.
If a time is specified, the blower automatically
switches off following head retraction.
ONE STROKE To eliminate a portion that remains uncut, unneces-
sary vertical motion of the cutter is omitted to permit
single-stroke cutting.
GDP Resolution is adjusted to the one supported by your
CAD.
ORIGIN A command origin is established that matches your
CAD.
Z STROKE The height of the tool, in its lifted position, from the
surface of a work to the bottom of tool is specified.
OH UNIT A value that is transmitted to the computer in return
to the command for the output of effective area
coordinate of the device.
ROTATE A direction in which data transmitted from applica-
tion software are to be turned by 90 is specified.
COMMAND SW The set values that are rendered effective are speci-
fied either those set on the operation panel or those
set on the personal computer.
PEN ASSIGN Pen numbers included in data are assigned to tools
of the device.
MULTI-PASS The number of times to perform cutting is set when
cutting a work that cannot be cut by performing
cutting once.
VA CUUM Setup the validity of the auto-off function.
P. 1.28
P. 4.11
P. 1.29
P. 4.8
P. 1.27
P. 1.26
P. 4.10
P. 1.25
P. 4.9
P. 1.24
P. 4.2
P. 4.6
P.1.31
To Next Page
