CONFIRMATION OF CUTTING QUALITY ONLY BY
THE SINGLE UNIT OF THE DEVICE [SELF TEST]
The “self-test” function is executed to determine where a trouble has occurred; i.e., either the com-
mand from the computer or the single unit of this device. The “self-test” function is used to conduct
plotting, cutting and marking of eleven different kinds of samples independently by the single unit
of this device without using any command from the computer. If cutting quality is poor, change the
cutting conditions and adjust tools. If the cutting quality cannot be improved after the aforemen-
tioned adjustments, contact your local dealer or MIMAKI office.
* Refer to Appendix C for sample.
Self-test items Description
CUT QUALITY 1 The device actuates using the tool selected by using the tool selecting function.
The sample used is a family emblem consisting of various line segments.
CUT QUALITY 2 The sample used is a pattern intended for the apparel industry. The device first
plots inner lines of the pattern. Then, it cuts outer lines of the pattern.
ASCII DUMP The device plots data transmitted from the computer with the ASCII code. This is
conducted to check for abnormal conditions of the data.
SAMPLE (COATED)
*1
This self-test is executed when creating a paper ware sample with coated board
(approximately 0.5 mm thick). Firstly, the device conducts marking, then cuts
the coated board along the outer shape of the pattern. To perform this test, coated
board of which size is equal to or more than A4 size is required.
Sample (E CORRUGATED)
*1
This self-test is executed when creating a paper ware sample with E corrugated
fiberboard (approximately 2 mm thick). Firstly, the device conducts marking,
then cuts the coated board along the outer shape of the pattern. To perform this
test, coated board of which size is equal to or more than A3 size is required.
Sample (B CORRUGATED)
*1
This self-test is executed when creating a paper ware sample with B corrugated
fiberboard (approximately 3 mm thick). Firstly, the device conducts marking,
then cuts the coated board along the outer shape of the pattern. To perform this
test, coated board of which size is equal to or more than A2 size is required.
R=3 The device cuts a circle of which radius is 3 mm.
R=5 The device cuts a circle of which radius is 5 mm.
R=10 The device cuts a circle of which radius is 10 mm.
R=20 The device cuts a circle of which radius is 20 mm.
R=50 The device cuts a circle of which radius is 50 mm.
R=100 The device cuts a circle of which radius is 100 mm.
PARAMETER DUMP The device plots a pattern according to the cutting conditions independently
established on it.
*1: Enabled in the RC model. Attach cutter holder 2N to unit B and use with vibration set to “OFF”.
