BASIC OPERATION ON THE LOCAL MENU
LOCAL menu
Various kinds of data and functions required for the connection with your personal computer are set.
Function Description Reference page
TOOL SELECTION Head and tool to be used are selected.
CONDITIONS Conditions for the tool selected using the [TOOL
SELECTION] function are specified.
TEST CUT Test cutting is performed so as to check that the
settings specified using the [CUTTING CONDI-
TIONS] function are proper.
DATA CLEAR Data received are cleared when aborting the cutting
(plotting) or in prior to the execution of the [COPY]
function.
COPY Cutting is performed again in accordance with the
data that have been once received.
VIEW Moves the head to the top right head retracting
position or bottom right and cap station.
INTERFACE Communication conditions for the serial port that
matches the personal computer to be used are
established.
MODE TEST Settings required to match the device to the personal
computer or application functions are specified.
SELF TEST Cutting is performed in accordance with sample data
so as to check the cutting quality or whether the
device itself has failed. In addition, data are plotted
using ASCII code or set values (parameters) for this
device are plotted as as to check for abnormal data.
CUT AREA Size of a work attached on the device or an area for
cutting is specified.
AXIS ALIGN If ruled lines such as scales are printed, mechanical
axes (X-axis, Y-axis) of the device are aligned to
them.
TOOL ADJUST Tools and relation between tools are adjusted.
P. 2.26
P. 2.28
P. 2.35
P. 2.48
P. 4.4
P. 2.7
P. 1.22
P. 4.14
P. 2.3
P. 5.2
P. 2.44
P. 4.16
P. 3.5
