ASSIGNMENT OF PEN NUMBERS [MODE SET] > [PEN ASIGN]
Pen numbers included in data are assigned to tools of the device. As many as six pens can be
assigned to the tools.
Operating procedure is described in this section using the example given below.
Pen 1 (Pen number in data to be plotted) → Pen
Pen 2 (Pen number in data to be cut) → Cutter 2
If the pen numbers are assigned as stated above, data on pen 1 and pen 2 an be plotted and cut at a
time.
1 Invoke the LOCAL menu on the
Press the
PAGE
+
key several times
until the LCD indicates page 3 of the
LOCAL MENU.
2 Select the [MODE SET].
3 Press the
PAGE
+
key several times
until the LCD indicates page 5 of the
[MODE SET].
4 Select the [PEN ASIGN].
5 Change the head from [B] to [A].
B, A
6 Set the tool to [PEN].
Pen, Swievel blade
[ LOCAL ] 1 / 4
TOOL SELECT ———>
CONDITION ———>
TEST CUT ———>
[ LOCAL ] 3 / 4
INTERFACE ———>
MODE SET ———>
SELF TEST ———>
< MODE SET > 1 / 5
Z STROKE ∗7 mm >
MULTI–PASS ———>
VACUUM ∗AutoOFF>
< MODE SET > 5 / 5
PEN ASIGN ———>
RESERVE
UNIT ∗mm >
< PEN ASIGN > 1 / 6
PEN 1
HEAD ∗B >
TOOL ∗RecCutter 1 >
< PEN ASIGN > 1 / 6
PEN 1
HEAD A >
TOOL ∗PEN >
PAGE
+
F1
+
F2
+
PAGE
+
F3
+
F2
+
