Introduction Patient Management
6 - 2 V Series Operating Instructions
6.1 Introduction
The V 12/V 21 comes with default factory settings which enable a clinician to begin monitoring
without setting any of the waveforms, parameters, alarms, or functions. However, all of these settings
can be changed for specific patient or departmental needs.
NOTE: Certain operating characteristics are based on the selected patient size
(e.g. NIBP start pressure). Match the patient size selection to the actual
patient before monitoring begins.
6.2 Patient Info Dialog
The Patient Info dialog (as shown in FIGURE 6-1) contains a Demographics tab, Room/Bed tab, and
a Transfer/Discharge tab. A description of each tab follows.
6.2.1 Navigating to the Patient Info Dialog
1. Select the Header Bar (located above the top waveform).
The Patient Info dialog displays (as shown in FIGURE 6-1).
OR
2. Select the Setup tab from the Navigation Area.
3. Select the Patient Info button.
The Patient Info dialog displays (as shown in FIGURE 6-1).
FIGURE 6-1 Example Patient Info Dialog (Demographics Tab)
