V Dock Physical Views General Product Description
1 - 10 V Series Operating Instructions
1.4 V Dock Physical Views
NOTE: Use the V Dock for the V 12 and the V 21 monitor.
1.4.1 Back View
1. Equipotential Lug
When using the monitor with other devices, connect their equipotential grounding terminals
together to eliminate the potential differences between them.
2. AC Receptacle (with an integrated cord retention clip)
3. V Hub Connector (MR 2-3)
4. Digital Video Interface (DV 1)
5. Central Station (CS 1)
FIGURE 1-7 Example V 12 V Dock Back View
