Mindray V21 User Manual

Addendum to V Series Operating Instructions 1 - 15
Continuous Cardiac Output (CCO) & Continuous Hemodynamics (Optional) Digital Tiles
5. Select the Cancel or Accept button to close the Hemo Tile Setup dialog.
•The Cancel button
closes the dialog without saving the settings.
•The Accept bu
tton saves the settings and closes the dialog.
6. Select the Cancel or Accept button to close the Hemo dialog.
•The Cancel button
closes the dialog without saving the settings.
•The Accept button saves the settings and closes the dialog.
1.4.12 Saving Hemo Calculations
To save the hemodynamic parameter calculations to the Hemodynamics Log:
To configure the parameters that display in the Hemo tile:
1. Select the Hemo tile.
2. Verify that there are calculations in the Hemodynamics Parameters table (as shown in FIGURE 1-
11).
FIGURE 1-11
Move to Bottom Moves the selected parameter to the bottom position in the Selected
list.
Scrolls up the Cho
i
ces or Selected lists.
Scrolls down the Choi
ces or Selected lists.
TABLE 1-4
BUTTON DESCRIPTION
